Type
L-Twin, Desmodromic distribution, 2 valves per cylinder, air cooled
Displacement
803 cc (49 cu in)
Bore and stroke
88 mm x 66 mm (3.5 in x 2.6 in)
Compression Ratio
11.0:1
Power
73 hp (53.7 kW) @ 8,250 rpm
Torque
65.2 Nm (6.6 kgm, 48 lb ft) @ 7,000 rpm
Fuel injection
Electronic fuel injection, 50 mm throttle body with Ride-by-Wire system
Exhaust system
Stainless steel muffler with catalytic converter, lambda probes, aluminium tail pipes
Gearbox
6 speed
Primary drive
1=32/13 2=30/18 3=28/21 4=26/23 5=22/22 6=24/26
Ratios
Straight cut gears, Ratio 1.85:1
Final drive
Chain, front spocket 15, rear sprocket 46
Clutch
Hydraulically controlled slipper and self-servo wet multiplate clutch
Frame
Tubular steel Trellis frame
Front suspension
Upside down Kayaba 41 mm fork
Front wheel
Spoked aluminium wheel 3.00″ x 17″
Front tyre
Pirelli Diablo Rosso IV - 120/70 R17
Real suspension
Kayaba rear shock, pre-load adjustable
Rear wheel
Spoked aluminium wheel 5.50″ x 17″
Rear tyre
Pirelli Diablo Rosso IV - 180/55 R17
Wheel travel
150 mm / 150 mm (5.9 in / 5.9 in)
Front brake
Ø330 mm disc, radial 4-piston caliper with Bosch Cornering ABS
Rear brake
Ø245 mm disc, 1-piston floating caliper with Bosch Cornering ABS
Instrumentation
4.3″ TFT colour display
Wet weight
183 kg (403 lb)
Seat height
808 mm (31.8 in)
Wheelbase
1,434 mm (56.5 in)
Rake
22°
Trail
92 mm (3.6 in)
Fuel tank capacity
14.5 l (3.8 US gal)
Number seats
1
Safety equipment
Riding Modes, Power Modes, Ducati Traction Control (DTC), Bosch Cornering ABS
Standard equipment
Ducati Quick Shift (DQS) up/down, TFT colour display, Full LED lighting system, Daytime Running Light (DRL), Self cancelling turn indicators, USB port
Ready for
Anti-Theft, Ducati Multimedia System (DMS), Heated grips, Turn-by-Turn navigation system
Warranty
24 months, unlimited mileage
Valve clearance check
12,000 km (7,500 mi)
Standard
Euro 5+
Co emissions
120 g/km
Consumption
5.2 l/100 km
